An innovative pressure die cast aluminium clamp that is suitable for 38mm to 51mm (1.50" – 2.01") diameter tubes. It has a WLL of 50Kg and is 30mm (1.18") wide. Slotted to hold captive an M10 nut or bolt head. Ideal for use with lightweight lanterns on trussing as it will not damage the cords. The perfect replacement for old style steel hook clamps. Available powder coated black.
Tube Diameter: O38 - 51mm (1.50” - 2.01”)
Materials :
Main Body - EN46500 Aluminium
Roll Pins - Stainless Steel
Eyebolt Assy - Grade 8.8
Max Tightening Τorque: Hand-tight Only
Fixings: To be used with M10 fixings
WLL: 50Kg Vertical Load
Weight 0.25Kg (0.54 lbs)
Factor of Safety 5:1
TUV Approved
