Features & Benefits

Heavy-duty sealed XLR connector range for harsh and demanding environment
IP65 rated and TOP approved in consideration to UL50E by mating with related cable or chassis connector of the XLR TOP range
Uses high impact UV-resistant materials
Maintains sealing when in use and when disconnected


Technical Information

Wiring: Solder contacts
Locking device: Latch lock
Mounting direction: Front mounting
Chassis shape: D
Locking element: Stainless steel
Flammability: UL94 V-0
Standard compliance: IEC 61076-2-103
Protection class: IP65
Solderability: Complies with IEC 68-2-20
Temperature range: -30 °C to +80 °C
