Freq. Response1 (-3 dB): 58 Hz - 18 kHz
Freq. Range1 (-10 dB): 39 Hz - 20 kHz
Rec. Hipass Frequency: 36 Hz
Axial Sensitivity1
: 98 dB (1W/1m)
Max. Calculated SPL: 132 dB
Horizontal Coverage: 90°
Vertical Coverage: 50°
Power Handling (Passive): 600W Continuous, 2400W Peak
LF Power Handling (Biamp): 500W Continuous, 2000W Peak
HF Power Handling (Biamp): 40W Continuous, 160W Peak
LF Transducer: DVX3150, 15 in (381mm) Driver
HF Transducer: ND2, 1 in (25.4mm) exit Neodymium
Compression Driver
Crossover Frequency: 1.5 kHz
Nominal Impedance: 8 Ohms
Minimum Impedance: 6.5 Ohms
Connectors: (2) Neutrik Speakon NL4’s
Enclosure Material: Polypropylene Structural Foam
Suspension: Enclosure has locations for 5 Single-Stud
Attachment Plates and 10 Forged Steel
Eyebolts - 2 on Top, 2 on Bottom, 2 on
Side, and 4 on Rear of Enclosure
Grille: Polyester Powder Coated, 16GA
Galvanized Steel, with Rotatable Logo
Environmental Spec: IEC 529 IP24 / IP44 (PI Version)
Dimensions (H x W x D): 692mm x 446mm x 411mm
(27.26” x 17.57” x 16.16”)
Net Weight: 22.2 kg (49.0 lbs)
Shipping Weight: 26.0 kg (57.4 lbs)
