Περιγραφή
Specification
Audio Connections
Input A / B: XLR, balanced
Input impedance: 10 kΩ balanced, 6.6 kΩ unbalanced
Max. input level: +21 dBu
CMRR: 64 dB typ. @ 1 kHz
Link A / B: XLR, balanced
Output 1 – 8: XLR, balanced
Max. output level: +28 dBu
System
Frequency response: 10 Hz to 75 kHz (±3 dB)
Dynamic range: 117 dB
Distortion (THD): 0.001% typ. @ +4 dBu, 1 kHz, Gain 1
Crosstalk: < -77 dB @ 1 kHz
Signal-to-noise ratio: 20 Hz to 20 kHz, > 97 dB @ 0 dBu
Function Controls / Switches
Output level: -? … + 15 dB, variable
Mode: 1 – 8 / 2 – 4, switchable
Displays
Power ON: LED indicator
Output level: 5-digit LED display: sig / -24 / -12 / 0 / clip
Mode: Status LED Indicator
Power Supply
Type: Switch-mode autorange power supply
Mains voltage: 100-240 V, 50/60 Hz
Power consumption: 15 W
Mains connection: Standard IEC receptacle
